9 OUTLINE DRAWINGS
9 - 3
(b) MR-J4-40A(-RJ)/MR-J4-60A(-RJ)
[Unit: mm]
Approx. 80
170
156
161
168
6
40
6
6
5
Approx. 21
6
Approx. 38.5
Approx. 69.3
CNP2
CNP1
CNP3
PE
φ
6 mounting hole
With
MR-BAT6V1SET
Lock knob
Mass: 1.0 [kg]
Screw size: M4
Tightening torque: 1.2 [N•m]
L2
N-
P3
L11
L21
P4
L3
L1
C
D
P+
PE
Terminal
CNP1
CNP2
V
W
U
CNP3
Mounting screw
Screw size: M5
Tightening torque: 3.24 [N•m]
6
156 ± 0.5
2-M5 screw
Mounting hole process drawing
Approx. 6
Approx. 6
Approx. 168
Approx. 40
301
303
