9 OUTLINE DRAWINGS
9 - 16
(f) MR-J4-11KA4(-RJ)/MR-J4-15KA4(-RJ)
[Unit: mm]
Approx.
38.5
Approx.
139.5
220
196 1212
6
400
38010 10
TE1-1
25.5
57.9
5 × 25.5 (= 127.5)
22.8
PE
TE2
1124.2
4360
78.5
TE1-2
188
237.4
224.2
260
10.5
Cooling fan
exhaust
Approx. 80
Approx. 28
With
MR-BAT6V1SET
Intake
2-φ6 mounting hole
Mass: 13.4 [kg]
TE1-2
TE2
Screw size: M6
Tightening torque: 3.0 [N•m]
Screw size: M4
Tightening torque: 1.2 [N•m]
PE
TE1-1
PE
Screw size: M6
Tightening torque: 3.0 [N•m]
Screw size: M6
Tightening torque: 3.0 [N•m]
N-P3 P4
TE1-1
L2 L3L1
CP+TE1-2
VWU
L11 L21TE2
Terminal
Mounting screw
Screw size: M5
Tightening torque: 3.24 [N•m]
0.5196
380 0.5
Mounting hole process drawing
Approx.
10
Approx. 400
Approx. 12Approx. 12
Approx. 220
4-M5 screw
Approx.
10
