10. CHARACTERISTICS
10 - 5
(Note 2) Servo amplifier-generated heat [W]
Servo amplifier Servo motor
(Note 1)
Power supply
capacity
[kVA]
At rated output
At rated output
[Generated heat
in the cabinet
when cooled
outside the
cabinet] (Note 3)
With servo-off
Area required for
heat dissipation
[m
2
]
HG-JR903 13 435 130 45 8.7
MR-J4-11KA(-RJ)
HG-JR11K1M 16 530 160 45 11.0
MR-J4-15KA(-RJ) HG-JR15K1M 22 640 195 45 13.0
MR-J4-22KA(-RJ) HG-JR22K1M 33 850 260 55 17.0
HG-SR524 1.0 40 18 0.8
MR-J4-60A4(-RJ)
HG-JR534 1.0 40 18 0.8
HG-SR1024 1.7 60 18 1.2
MR-J4-100A4(-RJ) HG-JR734 1.3 60 18 1.2
HG-JR1034 1.7 60 18 1.2
HG-SR1524 2.5 90 20 1.8
HG-SR2024 3.5 90 20 1.8
MR-J4-200A4(-RJ)
HG-JR1534 2.5 90 20 1.8
HG-JR2034 3.5 90 20 1.8
HG-SR3524 5.5 130 20 2.6
MR-J4-350A4(-RJ)
HG-JR3534 5.5 160 20 2.7
HG-SR5024 7.5 195 25 3.9
MR-J4-500A4(-RJ)
HG-JR5034 7.5 195 25 3.9
HG-SR7024 10 300 25 6.0
MR-J4-700A4(-RJ)
HG-JR7034 10 300
25 6.0
HG-JR9034 13 435 130 45 8.7
MR-J4-11KA4(-RJ)
HG-JR11K1M4 16 530 160 45 11.0
MR-J4-15KA4(-RJ) HG-JR15K1M4 22 640 195 45 13.0
MR-J4-22KA4(-RJ) HG-JR22K1M4 33 850 260 55 17.0
Note 1. Note that the power supply capacity will vary according to the power supply impedance. This value is applicable when the
power factor improving AC reactor or power factor improving DC reactor are not used.
2. Heat generated during regeneration is not included in the servo amplifier-generated heat. To calculate heat generated by the
regenerative option, refer to section 11.2.
3. This value is applicable when the servo amplifier is cooled by using the heat sink outside mounting attachment.
