11. OPTIONS AND AUXILIARY EQUIPMENT
11 - 59
(2) Selection example of crimp terminals
(a) 200 V class
Servo amplifier-side crimp terminals
Applicable tool
Symbol
(Note 2)
Crimp terminal
Body Head Dice
Manufacturer
a FVD5.5-4 YNT-1210S
b (Note 1) 8-4NS YHT-8S
c FVD2-4
d FVD2-M3
YNT-1614
e FVD1.25-M3 YNT-2216
f FVD14-6 YF-1 YNE-38
DH-122
DH-112
g FVD5.5-6 YNT-1210S
h FVD22-6 YF-1 YNE-38
DH-123
DH-113
i FVD38-8 YF-1 YNE-38
DH-124
DH-114
j FVD5.5-8 YNT-1210S
k FVD8-6 YF-1/E-4 YNE-38
DH-121
DH-111
JST
Note 1. Coat the crimping part with an insulation tube.
2. Some crimp terminals may not be mounted depending on the size. Make sure to use the
recommended ones or equivalent ones.
(b) 400 V class
Servo amplifier-side crimp terminals
Applicable tool
Symbol
Crimp terminal
(Note)
Body Head Dice
Manufacturer
a FVD5.5-4 YNT-1210S
b FVD2-4
c FVD2-M3
YNT-1614
d FVD5.5-6 YNT-1210S
e FVD5.5-8 YNT-1210S
f FVD2-6 YNT-1614
g FVD8-6
h FVD8-8
DH-121/DH-111
i FVD14-8
YF-1 YNE-38
DH-122/DH-112
JST
Note. Some crimp terminals may not be mounted depending on the size. Make sure to use the
recommended ones or equivalent ones.
