11. OPTIONS AND AUXILIARY EQUIPMENT
11 - 61
(2) For control circuit power supply
When the wiring for the control circuit power supply (L11, L21) is thinner than that for the main circuit
power supply (L1, L2, L3), install an overcurrent protection device (molded-case circuit breaker or fuse)
to protect the branch circuit.
Molded-case circuit breaker (Note) Fuse (Class T) Fuse (Class K5)
Servo amplifier
Frame, rated current Voltage AC [V] Current [A] Voltage AC [V] Current [A] Voltage AC [V]
MR-J4-10A(-RJ)
MR-J4-20A(-RJ)
MR-J4-40A(-RJ)
MR-J4-60A(-RJ)
MR-J4-70A(-RJ)
MR-J4-100A(-RJ)
MR-J4-200A(-RJ) 30 A frame 5 A 240 1 300 1 250
MR-J4-350A(-RJ)
MR-J4-500A(-RJ)
MR-J4-700A(-RJ)
MR-J4-11KA(-RJ)
MR-J4-15KA(-RJ)
MR-J4-22KA(-RJ)
MR-J4-60A4(-RJ)
MR-J4-100A4(-RJ)
MR-J4-200A4(-RJ)
MR-J4-350A4(-RJ)
MR-J4-500A4(-RJ) 30 A frame 5 A 480 1 600 1 600
MR-J4-700A4(-RJ)
MR-J4-11KA4(-RJ)
MR-J4-15KA4(-RJ)
MR-J4-22KA4(-RJ)
Note. When having the servo amplifier comply with the IEC/EN/UL/CSA standard, refer to appendix 4.
