OUTLINES AND DIMENSIONS
6
5
162
19
58
47
7.5315
255.547
2.5
98 173
98 173414.5 414.5
5225
253
791
56
1068
1100
325
Air out
Air in
Insulation [ 28
Drain hose [ 16
(Connected part O.D)
{
Liquid line [ 6.35- 0.5m
Gas line [ 12-0.43m
Insulation [ 50 O.D
[ 32 I.D
Installation plate
Wall hole [ 75
Wireless remote controller
Installation plate
Indoor unit
{
Liquid line [ 9.52- 0.5m
Gas line [ 12-0.43m
Insulation [ 50 O.D
[ 32 I.D
for MSH-A18/A24WV
for MSH-A30WV
Power supply cord
Lead to right 2.0m
Lead to left 1.0m
INDOOR UNIT
MSH-A18WV -
MSH-A24WV -
MSH-A30WV -
E1
E1
E1
Unit: mm
