PART NAMES AND FUNCTIONS
2
MSZ-EF09NAW MSZ-EF12NAW MSZ-EF15NAW MSZ-EF18NAW
MSZ-EF09NAB MSZ-EF12NAB MSZ-EF15NAB MSZ-EF18NAB
MSZ-EF09NAS MSZ-EF12NAS MSZ-EF15NAS MSZ-EF18NAS
ACCESSORIES
Model
MSZ-EF09NAW MSZ-EF12NAW MSZ-EF15NAW MSZ-EF18NAW
MSZ-EF09NAB MSZ-EF12NAB MSZ-EF15NAB MSZ-EF18NAB
MSZ-EF09NAS MSZ-EF12NAS MSZ-EF15NAS MSZ-EF18NAS
Installation plate 1
Installation plate fi xing screw 4 × 25 mm 5
Remote controller holder 1
Fixing screw for 3.5 × 16 mm (Black) 2
Battery (AAA) for remote controller 2
Wireless remote controller 1
Felt tape (For left or left-rear piping) 1
Soft dry cloth (NAB type only) 1
Air cleaning fi lter 2
Remote controller
Operation
indicator lamp
Remote control
receiving section
Emergency
operation switch
Horizontal vane
Air inlet
Air ¿ lter
(Nano platinum ¿ lter)
Air cleaning ¿ lter
(Electrostatic anti-allergy
enzyme ¿ lter)
Heat exchanger
Front panel
Air outlet
OBH736A
