Mitsubishi OUTLANDER Owner's Manual

No.
Sym-
bol
Electrical system
Ca-
paci-
ties
5 Alternator 7.5 A
6 Headlamp washer 20 A
7 Air conditioning 10 A
8
ETV/Oil cooler fan
(Twin Clutch SST)
15 A
9 Security horn 20 A
10 Wiper de-icer 15 A
11 — — —
12 Electric tailgate 30 A
13 Daytime running lamps 10 A
14
Headlamp high-beam
(left)
10 A
15
Headlamp high-beam
(right)
10 A
16
Headlamp
low beam
(left)
Discharge 20 A
17
Headlamp
low beam
(right)
Discharge 20 A
18
Headlamp
low beam
(left)
Halogen 10 A
*
: Fusible link
No.
Sym-
bol
Electrical system
Ca-
paci-
ties
19
Headlamp
low beam
(right)
Halogen 10 A
20 ENG/POWER 10 A
21 Ignition coil 10 A
22
ENG/POWER 20 A
Fuel line heater 25 A
23 Fuel pump 15 A
24 Starter
30 A
*
25 — — —
26 Anti-lock brake system
40 A
*
27 Anti-lock brake system
30 A
*
28
Air conditioning condens-
er fan motor
30 A
*
29 Radiator fan motor
40 A
*
30 IOD IOD 30 A
31 Audio system amp 30 A
32 Diesel 30 A
33 — Spare fuse 10 A
34 — Spare fuse 15 A
35 — Spare fuse 20 A
*
: Fusible link
l
Some fuses may not be installed on your ve-
hicle, depending on the vehicle model or spec-
ifications.
l
The table above shows the main equipment
corresponding to each fuse.
The fuse box does not contain spare 7.5 A, 25 A or
30 A fuses. If one of these fuses burns out, substi-
tute with the following fuse.
7.5 A: 10 A spare fuse
25 A: 20 A spare fuse
30 A: 30 A audio system amp fuse
When using a substitute fuse, replace with a fuse of
the correct capacity as soon as possible.
Identification of fuse
Capacity Colour
7.5 A Brown
10 A Red
15 A Blue
20 A Yellow
25 A Natural (White)
30 A
Green (fuse type)/
Pink (fusible link type)
40 A Green (fusible link type)
Fuse replacement
E01007800470
1. Before replacing a fuse, always turn off the
electrical circuit concerned and place the ig-
nition switch in the “LOCK” position.
Maintenance
8-22
8
