3. To install the bulb, perform the removal
steps in reverse.
NOTE
l
When installing the lens, align the hooks (B)
to the holes in the vehicle body.
Glove box lamp
E01006100434
1. Turn the socket (A) anticlockwise and re-
move it.
2. Remove the bulb.
3. To install the bulb, perform the removal
steps in reverse.
Vanity mirror lamps
E01006200233
1. Insert a straight blade (or minus) screwdriver
into the notch of the lens and pry gently to re-
move it.
Remove the bulb from the lamp holder.
NOTE
l
Wrap a piece of cloth around the tip of the
screwdriver in order to avoid scratching the
lens.
2. To install the bulb, perform the removal
steps in reverse.
Centre console down lamp
E01008700072
NOTE
l
An LED, not a bulb, is used in the centre con-
sole down lamp. Contact a MITSUBISHI
MOTORS Authorized Service Point when
there is a need for repair or replacement.
Maintenance
8-35
8
