Mitsubishi P91DW User Manual

7
Rear Panel
Select special functions.
Mode switches
C
PARALLEL data terminal
Function
Name
Reference
page
10
10
Connects to the device equipped with
parallel data interface such as personal
computer.
D
E
20 - 22
F
-
-
Power terminal (AC LINE)
Connect the power cord to this terminal.
Potential equalization terminal
Makes the connected equipment of
potential equal.
POTENTIAL EQUALIZATION
TERMINAL
This is used to equalize the potential of the equipment
connected to this unit.
For details refer to the installation instruction of
equipment to be connected.
AC LINE
1 2 3 4
OFF
ON
OFF
1 2 3 4
PARALLEL DATA IN
LOCK
ON
OFF
C
D
E
F

Mitsubishi P91DW Specifications

General

Brand	Mitsubishi
Model	P91DW
Category	Printer
Language	English
