NOTES : *1.Rating conditions (cooling)-Indoor : D.B. 26.7:(80°F), W.B. 19.4:(67°F) Outdoor : D.B. 35:(95°F), W.B. 23.9:(75°F)
(heating)-Indoor : D.B. 21.1:(70°F), W.B. 15.6:(60°F) Outdoor : D.B. 8.3:(47°F), W.B. 6.1:(43°F)
*2.Rating conditions(heating)-Indoor : D.B. 21.1:(70°F), W.B. 15.6:(60°F) Outdoor : D.B. -8.3:(17°F), W.B. -9.4:(15°F)
Operating range
Indoor intake air temperature
D.B. 35:(95°F), W.B. 21.7:(71°F)
D.B. 19.4:(67°F), W.B. 13.9:(57°F)
D.B. 26.7:(80°F), W.B. 19.4:(67°F)
D.B. 21.1:(70°F), W.B. 15.6:(60°F)
Outdoor intake air temperature
D.B. 46:(115°F)
D.B. -18:(0°F)*
D.B. 21.1:(70°F), W.B. 15:(59°F)
D.B. -11.1:(12°F), W.B. -12.2:(10°F)
Cooling
Heating
Maximum
Minimum
Maximum
Minimum
* In case that the wind baffle is installed. (In case that the wind baffle is not installed, the minimum temperature will be -5:(23°F)DB.)
Model name Indoor unit
PCA-A24KA PCA-A30KA PCA-A36KA PCA-A42KA
Outdoor unit
PUZ-A24NHA3-BS
PUZ-A24NHA3
PUZ-A30NHA3-BS
PUZ-A30NHA3
PUZ-A36NHA3-BS
PUZ-A36NHA3
PUZ-A42NHA3-BS
PUZ-A42NHA3
Cooling
Max. Capacity Btu/h 24,000 30,000 35,000 42,000
Rated Capacity Btu/h 24,000 30,000 35,000 42,000
Min. Capacity Btu/h 12,000 12,000 12,000 18,000
Total Input W 2340 3760 4630 4110
EER Btu/h/W 10.3 8.0 7.6 10.2
SEER Btu/h/W 16.8 14.5 14.4 15.8
Moisture Removal Pints/h 5.8 8.3 8.5 11.7
*1 SHF 0.73 0.69 0.73 0.69
Heating
Max. Capacity Btu/h 28,000 34,000 38,000 48,000
Rated Capacity Btu/h 26,000 32,000 37,000 45,000
Min. Capacity Btu/h 12,000 12,000 12,000 18,000
Total Input W 2310 3210 3190 3830
COP W/W 3.30 2.92 3.40 3.44
*1 HSPF (4/5) Btu/h/W 10.9 / 8.9 9.2 / 7.1 10.2 / 8.1 10.2 / 8.3
Heating
Rated Capacity Btu/h 18,000 23,000 25,000 30,000
at low ambient
Total Input W 2220 2940 2800 3820
*2 COP W/W 2.38 2.29 2.62 2.30
Power supply
Phase, Cycle, Voltage 1phase , 60Hz , 208/230V
Breaker size A 25 30
Voltage
Indoor - Outdoor S1-S2 AC 208 / 230V
Indoor - Outdoor S2-S3 DC24V
Indoor - Remote Controller DC12V
Indoor unit
MCA A
MOCP A
Fan Motor F.L.A.
Fan Motor Output W
Air flow DRY CMM
(Lo-M2-M1-Hi) WET CMM
Air flow DRY CFM
(Lo-M2-M1-Hi) WET CFM
External pressure Pa
Sound level dB(A)
(Lo-M2-M1-Hi)
External finish (Panel)
Dimension W : mm [inch]
Unit (Panel) D : mm [inch]
H : mm [inch]
Weight kg
Unit (Panel) lbs
Field drain pipe size O.D.
mm [inch] 26 [1-1/32]
Remote Controller
Attached in Indoor Unit
Outdoor unit
MCA A 18 25 26
MOCP A 30 40
Fan Motor F.L.A. 0.75 0.4 + 0.4
Fan Motor Output W 75 86 + 86
Compressor TNB220FLHM ANV33FDPMT
R.L.A 12 20
L.R.A. 14 17.5 27.5
Air flow CMM [CFM] 55 [1,940] 100 [3,530]
Refrigerant Control Linear Expansion Valve
Defrost Method Reverse Cycle
Sound level at cooling dB(A) 48 51
Sound level at heating dB(A) 50 55
External finish Ivory Munsell 3Y 7.8/1.1
Dimension W : mm [inch] 950 [37-3/8]
D : mm [inch] 330+30 [13 + 1-3/16]
H : mm [inch] 943 [37-1/8] 1350 [53-1/8]
Weight kg [lbs]
kg [lbs]
75 [165] 118 [260]
Refrigerant
Type R410A
Charge 3.0 [6 lbs 10 oz] 4.5 [10 lbs]
Oil L [oz] 0.87 (FV50S) [28] 1.4 (FV50S) [45]
Refrigerant pipe size
Gas side O.D. mm [inch] 15.88 [5/8]
Liquid side O.D. mm [inch] 9.52 [3/8]
Refrigerant pipe length
Height difference Max. 30m [Max. 100ft]
Length Max. 50m [Max. 165ft]
Refrigerant Piping
Not Supplied
Connection Method
Flared
12
15
0.54 0.97
95 160
15-16-17-19 22-24-26-28
14-15-16-18 20-22-24-26
530-565-600-670 775-850-920-990
495-530-565-635 705-775-850-920
0
33-35-37-40
16-17-18-20
15-16-17-19
565-600-635-705
530-565-600-670
35-37-39-41 37-39-41-43
23-25-27-29
21-23-25-27
810-885-955-1025
740-810-885-955
39-41-43-45
White Munsell 6.4Y 8.9/0.4
1600 [63]1280 [50-3/8]
680 [26-3/4]
230 [9-1/16]
32 36
71 79
38
84
