Mitsubishi PUHZ-SP100VHA User Manual

22
9 REFRIGERANT SYSTEM DIAGRAM
Unit : mm (inch)
Accumulator
Compressor
Refrigerant GAS pipe
15.88
mm([ 5/8)
Refrigerant LIQUID pipe
9.52
mm([ 3/8)
4-way
valve
Service port
(check)
High pressure protect switch
Linear expansion valve
Muffler
Stop valve
(#50)
Strainer
Strainer
(#100)
Strainer
(#100)
Stop valve
(with service port)
Strainer
(#40)
Thermistor (TH3)
Capillary tube
(
[ 4.0o [ 3.0o-L200)o2
Thermistor
(TH6)
Distributor
Bypass valve
Outdoor heat exchanger
Thermistor
(TH3)
Thermistor
(TH6)
Distributor
Service
port
(check)
Service
port
(check)
Accumulator
Compressor
Refrigerant GAS pipe
15.88mm([5/8)
Refrigerant LIQUID pipe
9.52mm([3/8)
Stop valve
(with service port)
4-way valve
Service
port
(check)
High pressure
protect switch
Linear expansion valve
Thermistor
(TH32)
Thermistor
(TH32)
Muffler
Stop valve
(#50)
Strainer
(#100)
Strainer
Strainer
(#40)
(#100)
Strainer
Refrigerant flow in cooling
Refrigerant flow in heating
PUHZ-SP100VHA.UK
PUHZ-SP100YHA.UK
PUHZ-SP125VHA.UK PUHZ-SP140VHA.UK
PUHZ-SP125YHA.UK PUHZ-SP140YHA.UK
OCH566A
