Mitsubishi Q00CPU User Manual

3
SEQUENCE PROGRAM CONFIGURATION AND
EXECUTION CONDITIONS
3.9 Numeric Values which can be Used in Sequence Programs
3.9.1 BIN (Binary Code)
3 - 83
1
Overview
2
Performance Specification
3
Sequence Program Configuration and Execution Conditions
4
I/O Nunber Assignment
5
Memories and Files Handled by CPU Module
6
Functions
7
Communication using built-in Ethernet ports of CPU module
8
Communication with Intelligent Function Module
POINT
To each bit of each register, a 2
n
value is assigned.
Note that an unsigned (no sign) binary number (0 to 65535) cannot be used since
the most significant bit is used for discrimination of sign (positive or negative).
1) When most significant bit is "0"...Positive
2) When most significant bit is "1"...Negative
