5 - 70
5.4 File Operation by GX Developer and Handling Precautions
5.4.3 Memory capacities of files
5
MEMORIES AND FILES HANDLED BY CPU MODULE
(3) When Universal model QCPU is used
When using the program memory, standard RAM, standard ROM or memory card,
calculate the rough size of each file according to Table 5.18
.
(Continued on next page)
Table5.17 Memory capacity calculation for files (Universal model QCPU)
Function Rough file capacity (unit: byte)
Drive heading 72
Parameter
Default: 464 (increases depending on the parameter setting)
*1
Reference
Boot setting 84 + (18 (number of files))
*2
CC-Link IE controller network setting made 72+(Total of parameter sizes per module)+
(Routing setting size) + (Size setting of transfer between data
links)
• Parameter size per module:
Up to 10368 (1826 + 16 (Number of refresh transfer points) for setting LB/LW(1) only)
• Routing setting size: 6 + 8 (Number of routing settings)
• Size setting of transfer between data links:
6+12 (Number of transfersettings)+86 (Number of modules)
MELSECNET/H setting made Max. 6180/module increased
Ethernet setting made Max. 922/module increased
CC-Link setting made Max. value of the table below increased
(The values of the table below indicate the increment of each module.)
Remote password setting made 92 + (number of target modules 10), max. 172 increased
Sequence program
148
*3
+ ((4 (number of steps) + (number of allocate memory for online change)))
Device comment
74 + 8 + (sum of comment data sizes of devices)
• Comment data size of one device = 10 + 10250 a + 40 b
• a : Quotient of ((device points)/256)
• b : Remainder of ((device points)/256)
Device initial value
66 + 44 n + 2 (total number of device points set for the device initial value) + 8
• n : Number of set device initial values
User setting area Value set at formatting (0 to 15k)
File register 2 (number of file register points)
CC-Link setting
Mode setting
Ver.1 mode Ver.2 mode Ver.2 additional mode
module 1 550byte 572byte 624byte
module 2 to module 4 536byte 558byte 610byte
module 5 550byte 566byte 618byte
module 6 to module 8 536byte 558byte 610byte
