Mitsubishi Q00CPU User Manual

6
FUNCTIONS
6.17 Self-diagnostics Function
6 - 135
1
Overview
2
Performance Specification
3
Sequence Program Configuration and Execution Conditions
4
I/O Nunber Assignment
5
Memories and Files Handled by CPU Module
6
Functions
7
Communication using built-in Ethernet ports of CPU module
8
Communication with Intelligent Function Module
: Self-diagnostics is performed, : Self-diagnostics is not performed
(Continued on next page)
Table6.35 Self-diagnostics list (Continued)
Diagnosics Error message Diagnostics timing
CPU
module
status
LED status CPU module
RUN ERR. 1) 2) 3) 4) 5)
Parameter
error
Parameter setting
check
PARAMETER
ERROR
• When the CPU
module is powered
on/reset
• When switched from
STOP to RUN
• When writing data to
the programmable
controller
Stop OFF Flash
Link parameter error
LINK
PARA.ERROR
• When the CPU
module is powered
on/reset
• When switched from
STOP to RUN
Stop OFF Flash
SFC parameter error SFC PARA.ERROR
• When switched from
STOP to RUN
• When writing data to
the programmable
controller
Stop OFF Flash
Intelligent function
module parameter
error
SP.PARA. ERROR
• When the CPU
module is powered
on/reset
Stop OFF Flash
Password error
REMOTE
PASS.ERR
• When the CPU
module is powered
on/reset
• When switched from
STOP to RUN
Stop OFF Flash
Program
error
Instruction code check
INSTRUCT. CODE
ERR
• When the CPU
module is powered
on/reset
• When switched from
STOP to RUN
• When an instruction
is executed
Stop OFF Flash
No END instruction MISSING END INS.
• When the CPU
module is powered
on/reset
• When switched from
STOP to RUN
Stop OFF Flash
Pointer setting error CAN'T SET(P)
• When the CPU
module is powered
on/reset
• When switched from
STOP to RUN
Stop OFF Flash
Pointer setting error CAN'T SET(I)
• When the CPU
module is powered
on/reset
• When switched from
STOP to RUN
Stop OFF Flash
