2.1 Basic model QCPU
2
PERFORMANCE SPECIFICATION
*5 : Each of parameter, intelligent function module parameter, sequence program, SFC program, device comment, and device initial value
files can be stored.
*6 : The number of points can be changed within the setting range. ( Section 10.2)
Table2.1 Performance Specifications
Item
Basic model QCPU
Q00JCPU Q00CPU Q01CPU
Max. number of
files stored
Program memory
6
*5
Memory card (RAM) ----
Memory
card
(ROM)
Flash card ----
ATA card ----
Standard RAM ---- 1
Standard ROM
6
*5
No. of times of writing data into the
standard ROM
Max. 100000 times
No. of I/O device points
(No. of points usable on program)
2048 points
(X/Y0 to 7FF)
No. of I/O points (No. of points accessible
to the actual I/O module)
256 points
(X/Y0 to FF)
1024 points
(X/Y0 to 3FF)
No. of device points
Internal relay [M] 8192 points by default (M0-8191) (changeable)
Latch relay [L] 2048 points by default (L0 to 2047) (changeable)
Link relay [B] 2048 points by default (B0 to 7FF) (changeable)
Timer [T]
*6
512 points by default (T0 to 511) (changeable)
(Sharing of low- and high-speed timers)
The low- and high-speed timers are specified by the instructions.
The measurement unit of the low- and high-speed timers is set up by parameters.
(Low-speed timer: 1 to 1000ms, 1ms unit, 100ms by default)
(High-speed timer: 0.1 to 100ms, 0.1ms unit, 10ms by default)
Retentive timer [ST]
*6
0 point by default (sharing of the low- and high-speed retentive timers) (changeable)
The low- and high-speed retentive timers are specified by the instructions.
The measurement unit of the low- and high-speed retentive timers is set up by parameters.
(Low-speed retentive timer: 1 to 1000ms, 1ms unit, 100ms by default)
(High-speed retentive timer: 0.1 to 100ms, 0.1ms unit, 10ms by default)
Counter [C]
*6
• Normal counter: 512 points by default (C0 to 511) (changeable)
• Interrupt counter: 128 points max. (0 point by default, setting by parameters)
Data register [D]
*6
11136 points by default (D0 to 11135) (changeable)
Link register [W]
*6
2048 points by default (W0 to 7FF) (changeable)
Annunciator [F]
*6
1024 points by default (F0 to 1023) (changeable)
Edge relay [V]
*6
1024 points by default (V0 to 1023) (changeable)
File
register
[R] ----
32768 points (R0 to 32767)/block
(The number of device points is fixed)
[ZR] ----
65536 points (ZR0 to 65535)
(The number of device points is fixed)
Link special relay [SB] 1024 points (SB0 to 3FF) (The number of device points is fixed)
Link special register [SW] 1024 points (SW0 to 3FF) (The number of device points is fixed)
