Specifications
Item
QJ72BR15
LX/LY 8192 points
LB
16384
points
Remote master station remote sub-master
station, remote I/O station: 8192 points
Remote sub-master station, remote I/O station
remote master station: 8192 points
Maximum number
of links per network
LW
16384
points
Remote master station remote sub-master
station, remote I/O station: 8192 points
Remote sub-master, remote I/O station
remote master station: 8192 points
Maximum number of links per
station
• Remote master station Remote I/O station *1
{(LY + LB) /8 + (2 × LW)} 1600 bytes
• Remote I/O station Remote master station *1
{(LX + LB) /8 + (2 × LW)} 1600 bytes
• Multiplexed remote master station
Multiplexed remote sub-master station
{(LY + LB) /8 + (2 × LW)} 2000 bytes
Maximum I/O points per
remote I/O station
X + Y
4096 points
If the X/Y numbers are duplicate, only one side is taken into
consideration.
Communication speed 10 Mbps
Communication method Token bus
Synchronization method Frame synchronization
Transmission path format Single layer bus
Maximum number of networks 239
Number of stations per
network
33 stations
(Remote master station: 1, Remote I/O stations: 32) *2
Overall distance
500 m(Between stations 500 m) (5C-2V)
300 m(Between stations 300 m) (3C-2V)
Can be extended up to 2.5 km with the use of a repeater
(A6BR10,A6BR10-DC)
Distance between stations *3
500 m (5C-2V)
300 m (3C-2V)
Connection cable
Coaxial cable
Equivalent to 3C-2V, 5C-2V *4 (Arranged by user)
Applicable connector
BNC-P-3-NiCAu (For 3C-2V), BNC-P-5- NiCAu (For 5C-2V)
Equivalent to (DDK) (Arranged by user)
Base unit installation position CPU slot
5 VDC internal current
consumption
1.10A
External dimensions
98 (3.86) (H) 27.4 (1.08) (W) 90 (3.54) (D) [mm(inch)]
Weight 0.16kg
