7 SCHEDULED MAINTENANCE
Mitsubishi Diesel Engine S16R & S16R2 OPERATION & MAINTENANCE MANUAL
123
Pub. No. K29001-00320 Revision: 1
*1: Service intervals vary depending on the use conditions. For details, see the rating definition "Rating
Definition" (→ Page 120).
Table 7-4 Scheduled Maintenance for Continuous Use Engine (2/3)
Inspection and Maintenance
Period
Service Items
Reference
Page
Service
period
Service hours
-
Every 2000
service hours
• Fuel Pipe - Check 152
• Oil Pipe - Check 163
-
Every 4000
service hours
* 1
• Engine - Top Overhaul (Remove the cylinder head, and
inspect and service the combustion chambers.)
174
(Contact your
SME dealer
• Turbocharger - Check 174
• Damper - Check 139
• Starter - Check 177
• Unit Seal and Oil Seal of Water Pump - Replace
• Protection System - Check
8
(Contact your
SME dealer)
• Resin Fan Inspection
(Blade Inspection/Cleaning, Bolt Looseness Check and
Tightening)
173
• LLC Concentration in Coolant - Check 114
-
Every 8000
service hours
* 1
• Engine - Major Overhaul (Disassemble the engine, and then
clean, check, and replace major parts.)
<At the major overhaul>
Parts to be replaced:
Inlet and exhaust valves, inlet and exhaust valve seat
O-rings, valve rotators, valve cotters, rocker arm
adjusting screws, valve push rods, bridge caps,
camshaft bushings, main bearings, cylinder liners,
main bearing cap bolts and washers, piston rings,
connecting rod bearings, damper, crankcase thrust
plates and consumable items (gaskets, oil seals, O-
rings, and others.)
8
(Contact your
SME dealer)
