8 INSPECTION AND MAINTENANCE
Mitsubishi Diesel Engine S16R & S16R2 OPERATION & MAINTENANCE MANUAL
166
Pub. No. K29001-00320 Revision: 1
7 Open the coolant drain cock (1) on
the engine body.
Coolant is drained.
Fig. 8-86 Coolant Drain Cock on Engine Body
8 Open the coolant drain cock (2) on
the water pump.
Coolant is drained.
Fig. 8-87 Coolant Drain Cock on Water Pump
■ Cooling System - Clean
When using the engine or radiator for the first time
or after a long term storage, clean the cooling
system.
1 Close the coolant drain cock (1) and
(2) on the engine body and water
pump.
Fig. 8-88 Coolant Drain Cock on Engine Body
Fig. 8-89 Coolant Drain Cock on Water Pump
(1)
(2)
When handling cleaning solution for
washing the cooling system, obey the
manufacturer's SDS.
* Improper wearing or using of personal
protective equipment may cause personal
injury.
(1)
(2)
