10 TRANSPORTATION
Mitsubishi Diesel Engine S16R & S16R2 OPERATION & MAINTENANCE MANUAL
186
Pub. No. K29001-00320 Revision: 1
For S16R
Fig. 10-1 Engine's Center of Gravity (S16R)
For S16R2
Fig. 10-2 Engine's Center of Gravity (S16R2)
Right Side View Engine Front View Left Side View
Crankshaft
Center
Center of Gravity
Center of GravityCenter of Gravity
Hanger
Center
70 mm
[2.76 in.]
70 mm
[2.76 in.]
838 mm
[32.99 in.]
822 mm
[32.36 in.]
768 mm
[30.24 in.]
822 mm
[32.36 in.]
768 mm
[30.24 in.]
752 mm
[29.61 in.]
502 mm
[19.76 in.]
502 mm
[19.76 in.]
722 mm
[28.43 in.]
722 mm
[28.43 in.]
220 mm
[8.66 in.]
220 mm
[8.66 in.]
395 mm
[15.55 in.]
395 mm
[15.55 in.]
698 mm
[27.48 in.]
892 mm
[35.12 in.]
Right Side View Engine Front View Left Side View
Crankshaft
Center
Center of Gravity
Center of GravityCenter of Gravity
Hanger
Center
30 mm
[1.18 in.]
30 mm
[1.18 in.]
799 mm
[31.46 in.]
822 mm
[32.36 in.]
769 mm
[30.28 in.]
822 mm
[32.36 in.]
769 mm
[30.28 in.]
792 mm
[31.18 in.]
739 mm
[29.09 in.]
852 mm
[33.54 in.]
577 mm
[22.72 in.]
577 mm
[22.72 in.]
792 mm
[31.18 in.]
792 mm
[31.18 in.]
215 mm
[8.46 in.]
215 mm
[8.46 in.]
457 mm
[17.99 in.]
457 mm
[17.99 in.]
