12. TECHNICAL INFORMATION
RWA000Z251
Information to identif
y
the model
(
s
)
to which the information relates to: If function includes heatin
g
: Indicate the heatin
g
season the
Indoor unit model name SRK63ZM-S information relates to. Indicated values should relate to one
Outdoor unit model name SRC63ZM-S heating season at a time. Include at least the heating season 'Average'.
Function(indicate if present) Average(mandatory) Yes
cooling Yes Warmer(if designated) No
heating Yes Colder(if designated) No
Item
s
y
mbol value unit Item s
y
mbol value class
Desi
g
n load Seasonal efficienc
y
and ener
gy
efficienc
y
class
cooling Pdesignc 6.30 kW cooling SEER 6.30 A++
heating / Average Pdesignh 7.10 kW heating / Average SCOP/A 4.11 A+
heating / Warmer Pdesignh - kW heating / Warmer SCOP/W - -
heating / Colder Pdesignh - kW heating / Colder SCOP/C - -
unit
Declared capacit
y
at outdoor temperature Tdesi
g
nh Back up heatin
g
capacit
y
at outdoor temperature Tdesi
g
nh
heating / Average (-10℃) Pdh 5.99 kW heating / Average (-10℃) elbu 1.11 kW
heating / Warmer (2℃) Pdh - kW heating / Warmer (2℃) elbu - kW
heating / Colder (-22℃) Pdh - kW heating / Colder (-22℃) elbu - kW
Declared capacity for cooling, at indoor temperature 27(19)℃ and Declared energy efficiency ratio, at indoor temperature 27(19)℃ and
outdoor temperature T
j
outdoor temperature T
j
Tj=35℃ Pdc 6.30 kW Tj=35℃ EERd 3.58 -
Tj=30℃ Pdc 4.64 kW Tj=30℃ EERd 5.40 -
Tj=25℃ Pdc 2.98 kW Tj=25℃ EERd 9.20 -
Tj=20℃ Pdc 4.24 kW Tj=20℃ EERd 9.00 -
Declared capacit
y
for heatin
g
/ Avera
g
e season, at indoor Declared coefficient of performance / Avera
g
e season, at indoor
temperature 20℃ and outdoor temperature Tj temperature 20℃ and outdoor temperature Tj
Tj=-7℃ Pdh 6.28 kW Tj=-7℃ COPd 2.37 -
Tj=2℃ Pdh 3.82 kW Tj=2℃ COPd 4.04 -
Tj=7℃ Pdh 2.46 kW Tj=7℃ COPd 5.80 -
Tj=12℃ Pdh 2.55 kW Tj=12℃ COPd 7.15 -
Tj=bivalent temperature Pdh 6.28 kW Tj=bivalent temperature COPd 2.37 -
Tj=operating limit Pdh 5.50 kW Tj=operating limit COPd 2.20 -
Declared capacit
y
for heatin
g
/ Warmer season, at indoor Declared coefficient of performance / Warmer season, at indoor
temperature 20℃ and outdoor temperature Tj temperature 20℃ and outdoor temperature Tj
Tj=2℃ Pdh - kW Tj=2℃ COPd - -
Tj=7℃ Pdh - kW Tj=7℃ COPd - -
Tj=12℃ Pdh - kW Tj=12℃ COPd - -
Tj=bivalent temperature Pdh - kW Tj=bivalent temperature COPd - -
Tj=operating limit Pdh - kW Tj=operating limit COPd - -
Declared capacit
y
for heatin
g
/ Colder season, at indoor Declared coefficient of performance / Colder season, at indoor
temperature 20℃ and outdoor temperature Tj temperature 20℃ and outdoor temperature Tj
Tj=-7℃ Pdh - kW Tj=-7℃ COPd - -
Tj=2℃ Pdh - kW Tj=2℃ COPd - -
Tj=7℃ Pdh - kW Tj=7℃ COPd - -
Tj=12℃ Pdh - kW Tj=12℃ COPd - -
Tj=bivalent temperature Pdh - kW Tj=bivalent temperature COPd - -
Tj=operating limit Pdh - kW Tj=operating limit COPd - -
Tj=-15℃
Pdh - kW
Tj=-15℃
COPd - -
Bivalent temperature
Operatin
g
limit temperature
heating / Average Tbiv -7 ℃ heating / Average Tol -15 ℃
heating / Warmer Tbiv - ℃ heating / Warmer Tol - ℃
heating / Colder Tbiv - ℃ heating / Colder Tol - ℃
C
y
clin
g
interval capacit
y
C
y
clin
g
interval efficienc
y
for coolin
g
Pc
y
c
c
- kW for coolin
g
EERc
yc
- -
for heatin
g
Pc
y
ch - kW for heatin
g
COPc
yc
- -
De
g
radation coefficient De
g
radation coefficient
cooling Cdc 0.25 - heating Cdh 0.25 -
Electric power input in power modes other than 'active mode'
Annual electricit
y
consumption
off mode Poff 10 W cooling Qce 351 kWh/a
standby mode Psb 10 W heating / Average Qhe 2421 kWh/a
thermostat-off mode Pto 50 W heating / Warmer Qhe - kWh/a
crankcase heater mode Pck 0 W heating / colder Qhe - kWh/a
Capacit
y
control
(
indicate one of three options
)
Other items
Sound power level(indoor) Lwa 59 dB(A)
Sound power level(outdoor) Lwa 62 dB(A)
fixed No Global warming potential GWP 1975 kgCO2eq.
staged No Rated air flow(indoor) - 1050 m3/h
variable Yes Rated air flow(outdoor) - 2910 m3/h
Contact details for obtainin
g
Name and address of the manufacturer or of its authorised representative.
more information
Mitsubishi Heav
y
Industries Air-Conditionin
g
Europe, Ltd.
7 Roundwood Avenue, Stockle
y
Park, Uxbrid
g
e, Middlesex, UB11 1AX,
United Kin
g
dom
