14
MK-100 TILE SAW PRODUCT SPECIFICATIONS
PRODUCT SPECIFICATIONS
The MK-100 is a versatile Tile Saw. Operated and used according to this manual, the MK-100
will provide years of dependable service.
GENERAL DESCRIPTION
MOTOR SPECIFICATIONS
BLADE CAPACITY
TILE TYPES
The MK-100 Tile Saw is engineered as a tabletop or stand mounted wet tile saw. The saw
includes a powerful 120V electric motor. The saw is capable of cutting tile up to twenty (20) inches
in length, depth of cut 3".
Motor specifications for the MK-100 are listed in below.
Voltage 120V
Motor Only Amperage 14.5
Frequency 60Hz
RPM 3400 rpm
Horse Power 1.5 hp
Weight 96 lbs.
The MK-100 uses a ten (10) inch (254 mm) diameter, wet cutting continuous rim, MK Diamond
blade with a five-eighths (5/8) inch (15.875 mm) arbor.
The MK-100 can cut a variety of tile types including stone, masonry, and lapidary products.
NOTE:
The MK-100 is not designed to cut plastic or metals.
A
B
D
C
E
J
I
H
G
F
A Motor
B Water Pump Tube
C Blade Guard
D Cutting Table
E Water Basin
F Frame
G Guide Bar
H Post
I Depth of Cut Adjustment Knob
J Belt Guard
