44
1
2
3
4
Blade Guard
Part# 152582
ITEM # DESCRIPTION PART # QTY.
1 SCREW, 5/16 - 18 X 1/2 SOCKET HD SET 152607 3
2 ELBOW, 1/2MNPT X 1/4 BARB, 90 DEG 154652 1
3 TUBE, WATER 155389 2
4 CASTING, 101 BLD GUARD-DC-COMP 162481 1
ITEM # DESCRIPTION PART # QTY.
1 WHEEL, ROLLER 151799 1
2 NUT, HEX, 1/4-20 151893 1
3 SCREW, HEX HEAD 1/4-20 X 1-12" 151914 1
4 WASHER, 1/4 SAE FLAT 151915 1
5 BRACKET, ROLLER WHEEL 154021 1
MK-100 EXPLODED VIEW & PARTS LIST
Roller Wheel Assembly Part # 151756
To Next Page
