Chapter Two: Installation Setu
p
9
Low Pressure Units 10 through 1200 Torr
1.50 (38.1) Dia.
0.19 (4.8)
1.84 (46.6)
0.99 (25.1)
4-VCR Fixed
Male Fitting
0.62 Hex Flat
Typ
0.92 (23.4)
1
/
4
" NPT Male
0.34 (8.6) Typ
1
/
8
" NPT Male
0.74
(18.8)
0.46
(11.8)
KF-16
Optional Fittings:
Figure 2: Dimensions of Low Pressure Single-Ended Units
