MKS 41A - Flying Leads Connector; Table 5: Pinout of the Flying Leads Connector; Trip Point Relay

Electrical Information Cha
p
ter Two: Installation
12
Flying Leads Connector
The flying leads connector has 2 foot long cable with six (6) leads. The color assignments are
listed in Table 5.
Pinout of the Flying Leads Connector
Wire Assignment
Red Power Input (+)
Black Power Return (-)
Green Relay Normally Open Contact
White Relay Common
Orange Relay Normally Closed Contact
Bare Wire Shield (Drain)
Table 5: Pinout of the Flying Leads Connector
Trip Point Relay
The trip point relay is a single pole, double throw switch, one normally open (NO), one normally
closed (NC) form “C” relay with contacts rated from 0.1 to 1 ampere, resistive. When the relay
is energized the normally open (NO) contacts will close. The action of the trip point, whether it
is energized above or below the trip point, is specified when the unit is ordered. Refer to
Appendix B: Model Code Explanation
, page 31, to determine the trip point action from the
model code of the unit. In addition, the serial number label, shown in Figure 7, page 17, lists the
trip point action.
