Appendix A: Product Specifications Electrical S
ecifications
29
Electrical Specifications
Input Power 10 to 20 VDC @ 35 mA maximum or
20 to 30 VDC @ 30 mA maximum
Relay Single pole, double throw switch, one normally open (NO),
one normally closed (NC) form “C” relay
Relay Contact Rating 1.0 A resistive at 30 VDC
Environmental Specifications
Operating Temperature Range 0° to 50° C (32° to 122° F)
Storage Humidity Range 25 to 70% relative humidity, non-condensing
Storage Temperature Range -20° to +80° C (-4° to 176° F)
Due to continuing research and development activities, these product specifications are subject to change without notice.
