Attach the leg panels [7] to the bottoms of panels [1] and [2] as shown.
2a: Join panels [3] together as shown using 2x connectors (C) and 2x
connectors (B) and secure with 4x washers (F) and 8x 20mm bolts (N). Tighten
with the allen key (T-2).
2b: Attach panels [3] to panels [1] and [2] using 2x left plates (L) and 2x right
plates (R) as shown. Secure with 8x 20mm bolts (N) and the allen key (T-2).
2c: Secure the other side of the plates as shown using 8x washers (F), 8x
spring washers (E), and 8x 25mm bolts (D). Tighten with the allen key (T-2).
2
7
1 7
7
7
7
L
R
L
R
2a
2c
2b
L
E
D
F
T-2
F
N
T-2
N
T-2
L
C
B
3
3
3
3
2
1
N
3
4
3a: Attach panel [9] to connectors (B) using 2x 25mm bolts (I) and 2x nuts
(G). Tighten with the allen key (T-3) and spanner (T-4). 3b: Attach panels
[4] and [5] as shown using 4x 20mm bolts (N). 3c: Secure the centre join
and leg [6] as shown with 1x 35mm bolt (H). 3d: Attach the other legs [6]
as shown using 4x 25mm bolts (I). Tighten with the allen key (T-3).
Join each panel [8] to a double cap (A) and attach to panels [4] and [5].
Slot the ends of panels [8] into panels [3] as shown. Carefully lift the bed
into the desired position, do not drag. You’re done, enjoy!
