Mod 101 - Page 58

T-12AX7-S-JJ 1 12AX7/ECC83 preamp tube
T-12AT7-JJ 1 12AT7/ECC81 preamp tube
T-6L6GC-JJ-MP 1 matched pair of 6L6GC power tubes
T-EL34-JJ-MP 1 matched pair of EL34 power tubes
P-Q1N4007 3 solid state diode
blk
red
P-H1600 1 impedance selector switch and output jack
wiper
hotcold cold
wiper
hot
R-V38-250KA 2 250kΩ potentiometer (audio taper)
wiper
hotcold cold
wiper
hot
R-V38-1MA 1 1MΩ potentiometer (audio taper)
wiper
hotcold cold
wiper
hot
R-V38-25KL 1 25kΩ potentiometer (linear taper)
P-K300 4 black chicken head knobs
P-H1200 1 Strain Relief
S-H142 2 tube clip
P-ST8-807 2 octal tube socket
P-ST9-700 2 nine pin miniature tube socket
P-G005 5 rubber grommet
S-H33-097 1 input jack
P-L121 1 purple jewel
P-H35-146 1 power switch (DPDT)
Parts List 3
BAG 5
BAG 6
BAG 3
BAG 3
BAG 4
BAG 5
BAG 5
BAG 5
BAG 5
BAG 4
BAG 4
BAG 4
BAG 4
BAG 4
