Mod Nexus Series - Page 5

P-Q971
Main PCB Parts List (cont.)
P-QLM311
LT1054 Voltage Converter IC, 8-Pin DIP
1N4148 Small Signal Diode
LM311 Comparator, 8-Pin DIP
P-QLT1054
Qty 2
Qty 1
Qty 1
Phase / Off
4
C-R82-1N
1nF Box Film Capacitor
Qty 4
C-D10P-50
10pF Ceramic Capacitor
Qty 1
P-Q2N2222A-92
2N2222A NPN Transistor
Qty 1
P-QTL074
8-Pin DIP Socket
TL074 Quad Op Amp IC, 14-Pin DIP
P-STIC-8
Qty 1
Qty 2
P-Q1N5817
1N5817 Schottky Diode
Qty 1
C-R82-1N5
1.5nF Box Film Capacitor
Qty 1
C-R82-100N
100nF (.1uF) Box Film Capacitor
Qty 1
C-R82-470N
470nF (.47uF) Box Film Capacitor
Qty 2
TOP
DOWN
VIEW
TOP
DOWN
VIEW
TOP
DOWN
VIEW
TOP
DOWN
VIEW
TOP
DOWN
VIEW
C-D47P-50
47pF Ceramic Capacitor
Qty 1
TOP
DOWN
VIEW
C-CD470-500
470pF Ceramic Capacitor
Qty 1
TOP
DOWN
VIEW
C-D100N-50
100nF Ceramic Capacitor
Qty 6
TOP
DOWN
VIEW
C-ETR100-25
100uF Electrolytic Capacitor
Qty 3
TOP
DOWN
VIEW
TOP
DOWN
VIEW
14-Pin DIP Socket
P-STIC-14 Qty 1
