LED State Mode
On Off No or not enough power
Green Sufficient voltage connected
Green + blinking
orange (red & green)
Standard mode
MC ready
WLAN Off WLAN option off
Blinking red MC is looking for suitable APs or is
currently authenticating
Green Wireless LAN connection works.
Short orange blinking shows activity
(sending or receiving of data) at the
interface.
LAN
Off No device connected to the LAN-Port
Green Device connected to LAN-Port.
Short orange blinking shows activity
(sending or receiving of data) at the
interface.
Serial Off The interface is inactive.
Green A partner-device is connected to the
interface. Short orange blinking shows
activity (sending or receiving of data) at
the interface.
Blinking green The interface is ready and awaits a
connection.
Table 1: LED-Modes
1.5 Technical Properties
Specifications:
Ethernet 1, 2 or 4 x 10/100/1000 MBit Auto MDI/MDIX
Serial 1 x RS232, 300-460,8 KBit/s, RTS, CTS, DSR, DTR, RI, DCD
or (optional) RS485
USB 1 x USB 2.0
Relay 1 x Switch over, max 1A@24V, max 125VAC
Signal Input 1 x galv. separated 10 – 72V
Antenna Connectors 2 x RPSMA (optional TNC or RPTNC)
Power Supply 10 – 72VDC or 802.3af PoE via LAN Port1
Energy <= 5W (typically 3W)
Temperature 0-60°
MC Manual Version 2.10c
