OPERATING MANUAL STEAM SYSTEM
www.modbar.com Document 003-0042-1.1| Software Version 2.0
home -> main settings -> file operations -> save settings
File list: This area displays all of the settings files that are currently saved to the USB drive.
New file: This option allows the creation of a new settings file. To create a new settings file, highlight
the < new file > option, and select it by either pressing the center encoder button or the file select
button on the touch screen.
Cursor select: The dotted outline cursor select indicates which file is selected on screen. You may use
the rotary encoder or up/down function of the joystick to navigate the file list.
File select button: Pressing select will save the current settings to the selected file. This includes all
user accessible settings and preferences.
