Moduline HHT 052 E - General Recommendations and Technical Data

GENERAL RECOMMENDATIONS
AND TECHNICAL DATA
GB
Ed. 0722
16
Example of rating plate
TECHNICAL DATA
Model (type)
Rated voltage
[Vac]
Total input
[kW]
Amps.
[A]
Cable according to IEC-60245-57
(H05RN-F or HO7RN-F). Minimum cross
section of connection cable
[
mm2
]
HHT
052E (
HHT
052E)
230 50Hz
220 - 240
50 / 60 Hz
1,5 6,6
3 x 1
HHT
081E (
HHT
081E)
1 4,4
HHT
082E (
HHT
082E)
1,5 6,6
HHT
161E (
HHT
161E)
2 8,7
HHT
162E (
HHT
162E)
3 13,1
3 x 1,5
HHT
282E (
HHT
282E)
3 13,1
HHT28
1
E (HHT28
1
E)
2 7,8 3 x 1
Model
(type)
Operating
temperature
(°C)
Tray capacity:
distance [mm]
Tray max. height [mm]
Maximum total load
(product + trays)
h65 GN1/1) [kg]
Weight when
empty [kg]
HHT052E
(HHT052E)
30 ÷ 120
5 x GN 2/1 (75) 5 x 65 (h) 2 x 150 (h)
1 x 200 (h)
+ 2 x 65 (h)
36 + 15 51
10 x GN 1/1 (75) 10 x 65 (h) 4 x 150 (h)
2 x 200 (h)
+ 4 x 65 (h)
HHT081E
(
HHT
081E)
8 x GN 1/1 (75) 8 x 65 (h) 3 x 150 (h)
2 x 200 (h)
+ 2 x 65 (h)
29 + 12 46
HHT082E
(HHT082E)
8 x GN 2/1 (75) 8 x 65 (h) 3 x 150 (h)
2 x 200 (h)
+ 2 x 65 (h)
58 + 24 62
16 x GN 1/1 (75) 16 x 65 (h) 6 x 150 (h)
4 x 200 (h)
+ 4 x 65 (h)
HHT161E
(
HHT
161E)
16 x GN 1/1 (75) 16 x 65 (h) 6 x 150 (h)
4 x 200 (h)
+ 4 x 65 (h)
58 + 24 88
HHT162E
(HHT162E)
16 x GN 2/1 (75) 16 x 65 (h) 6 x 150 (h)
4 x 200 (h)
+ 4 x 65 (h)
115 + 48 106
32 x GN 1/1 (75) 32 x 65 (h) 12 x 150 (h)
8 x 200 (h)
+ 8 x 65 (h)
HHT282E
(HHT282E)
8 x GN 2/1 (75)
+
8 x GN 2/1 (75)
8 x 65 (h)
+
8 x 65 (h)
3 x 150 (h)
+
3 x 150 (h)
2 x 200 (h)
+ 2 x 65 (h)
+
2 x 200 (h)
+ 2 x 65 (h)
115 + 48 111
HHT281E
(HHT281E)
8 x GN 1/1 (75)
+
8 x GN 1/1 (75)
8 x 65 (h)
+
8 x 65 (h)
3 x 150 (h)
+
3 x 150 (h)
2 x 200 (h)
+ 2 x 65 (h)
+
2 x 200 (h)
+ 2 x 65 (h)
58 + 24 94
