MOD-5473/5474
FULL/QUEEN BED FRAME
STEP 1:
Insert the end of
Leg (3) into Short Board (1) and
Board
(2)
as
shown.
Secure by using 4 pieces of Bolt
s
(
A)
,
tighten Bolts (A) by using A
Repeat the same steps for the remaining 3 pieces of Legs
(3).
.
Ax16
Cx1
Hardware & Tool required
1
1
2
2
3
3
3
3
3
2
1
A A A
A
C
Bx8
Fx1
Hx8
Ix4
Dx1
Kx12
Hardware & Tool
STEP 2:
Place 1 piece of Support
Leg
(6) under
Center Rail (5) as shown.
Insert 2 pieces of
Bolts (H)
t
hrough the holes on
Center Rail (5) into the holes on Support Legs (6 )
as shown.
Tighten Bolts (H) with 2 pieces of
Nuts (B)/Flat Washer (K)
by using Allen Wrench (F) and Open Wrench (D) until Secure.
Secure one end of Center Rail (5) by using 2 pieces of Bolts (I) with 2 pieces of Flat Washers (K)
as shown.
Tighten Bolts (I)
by using Allen Wrench (F)
Repeat the same steps for the other end of Center Rail (5).
1
1
2
2
5
6
6
5
6
1
5
I
K
I
F
H
H
D
B
B
F
K
K
K
Lx16
L
L
L
L
6
6
Dot not fully tighten Bolts (A) at this step.
the middle
Dot not fully tighten Bolts (H) at this step.
Repeat the same steps
for the remaining Legs
(6)
.
1
2
3
insert
Long
and
