Customer Service 908-368-1025︱www.modwayfurniture.com Page 6 of 6
A or Bx4 Cx4 Dx4 Fx1
Hardware & Tool required
STEP 2:
2
Assembly is completed. The bed is ready to use now!
NOTE: Hardware may loosen over time. Periodically check that all conn
ections are tight.
1
1
2
AorB
D
C
F
Line up the Bed Fame (2) board’s pre-dr
illed holes to match those of the Headboard (1).
Secure the Headboard (1) to the Bed Frame (2) by using 2 pieces of Bolt (B) with 2 pieces of Spring Washer (D), 2 pieces
of Arc
Washer (C) for the thicker
Bed Frame (2), and 2 pieces of Bolt (A) with 2 pieces of Spring Washer (D), 2 pieces of
Arc Washer (C)
for the thinner
Bed Frame (2).
Then tighten the
Bolts (A or B) by using the Allen Wrench (F).
Repeat the same procedure for each bolt and each side of the Bed Frame (2).
STEP 1:
MODWAY CONNECTING HEADBOARD TO BED FRAME
Carefully position the assembl
ed bed to the desired location by
four adults.
