Customer Service 908-368-1025︱www.modwayfurniture.com Page 6 of 6
A or Bx4 Cx4 Dx4 Fx1
Hardware & Tool required
STEP 2:
2
Assembly is completed. The bed is ready to use now!
NOTE: Hardware may loosen over time. Periodically check that all connections are tight.
1
1
2
A
D
C
F
Line up the Bed Fame (2) board’s pre-drilled holes to match those of the Headboard (1).
Secure the Headboard (1) to the Bed Frame (2) by using 2 pieces of Bolt (B) with 2 pieces of Spring Washer (D), 2 pieces
of Washer (C) for the thicker Bed Frame (2), and 2 pieces of Bolt (A) with 2 pieces of Spring Washer (D), 2 pieces of
Washer (C) for the thinner Bed Frame (2).
Then tighten the Bolts (A or B) by using the Allen Wrench (F).
Repeat the same procedure for each bolt and each side of the Bed Frame (2).
STEP 1:
MODWAY CONNECTING HEADBOARD TO BED FRAME
Carefully position the assembled bed to the desired location by four adults.
