Installing tripod mounting plates
MoErgo makes mounting plates available for Glove80 to easily attach to a camera tripod or
other mount using the standard tripod mount screws (1/4"-20). They come in two types: quck
release or non-quick release.
To mount the tripod plate onto a Glove80 half:
1. Prepare the mounting plates. Please read Preparing the non-quick-release tripod
mounting plate or Preparing the quick release mounting plate, as appropriate for the type
of tripod mounting plate you have.
2. For the extensible legs, remove the feet by rotating them to reveal M4 studs. Remember
the original locations. Do not mix.
3. For the fixed leg, use a craft knife to remove the silicone bumper to reveal an M4 stud.
Do not throw away this silicone bumper; please wrap it in wax paper or Glad wrap for
safekeeping. Mark, it as “Silcone bumper for Glove80 fixed leg” in case you need to use
it again in the future. This silicone bumper is different from the others.
4. Turn the keyboard half upside down.
5. For the palm rest short leg, Add a foot without a silicone bumper, as a spacer, then
screw in a 16mm threaded rod through the spacer into the M4 stud in the palm rest.
6. Position a foot without a silicone bumper, as a spacer, for each extensible leg (other than
the palm rest short leg).
.
7. Put the tripod mounting plate over the up-turned half, lining up the holes in the tripod
mounting plate with the legs.
8. For all feet removed in step 2 (other than the one for the palm rest short leg) screw the
feet through the spacer foot into the M4 studs in the same leg.
9. For the fixed leg, use the feet removed from the palm rest short leg in step 2, and screw
the feet into the M4 stud.
10. For the palm rest short leg, screw in another foot without a silicone bumper on top of the
acrylic plate. Then apply a silicone feet from the accessories bag that comes with
Glove80.
Page 40 Glove80 User Guide
