-6-
Revision 5/F3528
LOCATION
This oven must be installed in an area of
adequate air supply. The following minimum
clearances for air openings, servicing,
operation and installation are to be adhered to:
Rear 75mm / 3”
Left-hand side 75mm / 3”
Right-hand side 75mm / 3
Top 200mm / 8”
(or 600mm from a
combustible surface.)
Floor 127mm / 5”
OVEN INTERNAL DIMENSIONS
Width 468 mm / 18.5”
Height 533 mm / 21”
Depth 711 mm / 28”
Oven Volume 0.18 m³ / 6.3 ft³
OVEN RACK SIZE
Width 460 mm / 18”
Depth: 660 mm / 26”
GAS SUPPLY SPECIFICATION OPTIONS
Natural LPG/Prop
(G20 UK) (G31 UK)
Input Rating 35 MJ/hr 35 MJ/Hr
33 000 Btu/hr 33 000 Btu/hr
9.5 kW 9.5 kW
Gas Rate 0.91 m³/hr 0.67 kg/hr
32.1 ft³/hr 1.48 lb/hr
Supply 1.13 kPa 2.75 kPa
Pressure 4.5”w.c. 11.0”w.c.
(Not USA/Can/UK)
Operating 0.90 kPa 2.25 kPa
Pressure 3.6”w.c. 9.0”w.c.
(Not USA/Can/UK)
Operating 10 mbar 35 mbar
Pressure
(UK only)
Operating 1.13 kPa 2.75 kPa
Pressure 4.5”w.c. 11.0”w.c.
(USA/Can only)
GAS CONNECTION SPECIFICATIONS
½” BSP female - Not USA / Canada
½” NPT female - USA / Canada only
ELECTRICAL SUPPLY SPECIFICATION
OPTIONS
110-120 V AC, 60 Hz, 2.0 A, 1 Phase
220-240 V AC, 50 Hz, 0.7 A, 1 Phase
230-240 V AC, 50 Hz, 0.55A, 1 Phase
220-240 V AC, 60 Hz, 0.7 A, 1 Phase
ELECTRICAL PLUG SPECIFICATION
REQUIREMENTS
Australia AS 2124, 10 Amp, 3 pin
Canada NEMA 5-15, 15 Amp, 3 pin
New Zealand AS 2124, 10 Amp, 3 pin
United Kingdom BS 1363A 13A fused, 3 pin
United States NEMA 5-15, 15 Amp, 3 pin
Other Countries Type to meet country
standards
BURNER INJECTOR ORIFICE SIZE
LPG/Prop/Butane 1.70 mm / No 51 drill size
Propane (G31) 1.55 mm (UK only)
Natural 2.70 mm / No 36 drill size
Natural (G20) 2.60 mm (UK only)
WATER SUPPLY CONNECTION
Max Pressure 550 kPa / 5.5 bar / 80 psi
Min Pressure 100 kPa / 1.0 bar / 15 psi
AUTOMATIC IGNITION CONTROL
110 Volt Models (24 Volt ignition system)
2 re-ignition attempts after burner ignition
failure. 30 second purge time between
ignition attempts. Lock-out condition after 3
ignition failures.
2 re-ignition attempts in the event of flame
loss during burner operation. 30 second
purge time between ignition attempts. Lock-
out condition after 2 re-ignition attempt
failures.
220-240 Volt Models*
Lock-out condition after burner ignition failure.
No re-ignition attempt.
1 re-ignition attempt in the event of flame loss
during burner operation. Lock-out condition if
re-ignition failure.
* Specifications apply to units from serial
number 203927.
NOTE:
Refer to Appendix B for further
ignition control specifications.
