-60-
Revision 5/F3528
47 015324 GAS VALVE BRACKET
48 014889 HEAT BOX REAR
49 015327 BURNER SUPPORT BRACKET
50 014890 HEAT BOX L.H SIDE
51 015537 INSULATION KEEP CHANNEL REAR
52 014728 BURNER BOX DEFLECTOR
53 SA1530 IGNITION ELECTRODE ASSEMBLY (FROM S/N 218596) (SEE SECTION
11.3.1)
015115 IGNITION ELECTRODE ASSEMBLY (TO S/N B47875) (SEE SECTION
11.3.3) - OBSOLETE: UPGRADE WITH SA1530
018760 IGNITION ELECTRODE ASSEMBLY (UK ONLY TO S/N B47875) (SEE SEC-
TION 11.3.4) - OBSOLETE: UPGRADE WITH SA1530
SA1021 IGNITION ELECTRODE ASSEMBLY (ALL FROM S/N B47875 TO S/N
218595) (SEE SECTION 11.3.2) OBSOLETE: UPGRADE WITH SA1530
54 014977 INSULATION KEEP CHANNEL FRONT
55 004352 PIPE MOUNTING BRACKET
56 015090 GAS PIPING ASSEMBLY (SEE SECTION 11.4)
57 004312 BURNER
58 014888 HEAT BOX FRONT
59 014943 INSULATION - HEAT BOX
60 004713 BOTTOM PANEL
61 004733 SIDE SERVICE PANEL
62 004714 INJECTOR ACCESS PANEL
63 015274 LEG ASSEMBLY 6"
015275 LEG TUBE WA - PLATED
010990 ADJUSTABLE FOOT
64 015575 SIDE RACK L.H
65 015168 OVEN RACK
66 015656 FAN BAFFLE
67 014031 OVEN BAFFLE STUD
019367 OVEN BAFFLE STUD (UK ONLY)
68 015930 BAFFLE LOCATING BRACKET
69 004397 RADIATION BAFFLE ENAMELLED
70 021526 WATER INLET ELBOW
021527 WATER INLET WASHER
71 020851 WATER SOLENOID - 240V
021617 WATER SOLENOID - 110V (USA/CANADA)
72 021618 WATER SOLENOID BRACKET
73 020869 CONNECTOR - 3/8"F x ¼" COMPRESSION
74 021058 WATER TUBE
75 021057 SPRAY NOZZLE ASSEMBLY
76 015591 JUNCTION BOX
77 002441 INSULATOR
78 002138 CABLE CLAMP
79 014185 MAINS TERMINAL BLOCK
80 021520 OVEN SEAL ASSEMBLY - VERTICAL
021522 SIDE SEAL - 0.55M
81 021517 OVEN SEAL ASSEMBLY - HORIZONTAL
021519 TOP SEAL - 0.52M
82 020082 TOP HINGE ASSEMBLY
017905 BUSH
83 021532 DOOR TRIM
84 021466 DOOR HANDLE BRACKET PLATED
85 021468 HANDLE
86 021441 CONTROL PANEL MOUNTING BRACKET
87 ---------- CONTROL ASSEMBLY (SEE SECTION 11.2)
88 021443 DOOR OUTER GLASS
090225 SILICONE EXTRUSION - 1.2M
89 004451 GLASS CLAMP ANGLE PAINTED
90 002340 DOOR INNER GLASS
090200 SILICONE EXTRUSION - 1.74M
91 020083 BOTTOM HINGE ASSEMBLY
017905 BUSH
92 004725 DOOR INNER
