-10-
Revision 5/F3528
6. Screw the chimney to the rear of the top
unit with these so that the bottom of the
chimney mates up with the flue duct of the
bottom unit. Screw together with four
remaining
3
/
8
” x 8 Phillips screws supplied.
Figure 2.4
Rating Plate
Figure 2.6
Units manufactured up to July 2002.
The rating plate for the G32 convection oven
is located at the bottom right corner of the RH
side panel.
RATING PLATE LOCATION
Units manufactured from July 2002.
The rating plate for the G32 convection oven
is located at the RH side front bottom corner.
Rating Plate
Figure 2.5
