Moffat turbofan E25 - Page 15

Revision 6/F3501
© Moffat Ltd, August 2006 E25 Convection Oven
-15-
FAULT POSSIBLE CAUSE REMEDY
BROIL ELEMENT NOT
WORKING (E25B ONLY)
Element faulty / blown.
(Refer fault diagnosis 6.1.12)
Faulty thermostat.
(Refer fault diagnosis 6.1.12)
Heating relay faulty
(Refer fault diagnosis 6.1.12)
Broil relay faulty
(Refer fault diagnosis 6.1.12)
Replace.
(Refer service section 6.3.9)
Replace.
(Refer service section 6.3.7)
Replace.
(Refer service section 6.3.8)
Replace.
(Refer service section 6.3.8)
NO BROIL INDICATOR LIGHT
(E25B ONLY)
Indicator faulty.
(Refer fault diagnosis 6.1.13)
Replace.
(Refer service section 6.3.3)
OVEN OVERHEATS IN BROIL
MODE—DOOR SHUT (E25B
ONLY)
Faulty heating relay.
(Refer fault diagnosis 6.1.14)
Replace.
(Refer service section 6.3.8)
DOOR DOES NOT CLOSE Tray in way of door.
Door seal obstruction.
Door hinges worn.
Door hinge counter brackets
worn.
Correctly position tray in rack.
Correctly install door seal.
(Refer service section 6.3.14)
Replace.
(Refer service section 6.3.16)
Replace.
(Refer service section 6.3.17)
DOOR SEAL LEAKS Door seal damaged.
Door seal incorrectly fitted.
Replace.
(Refer service section 6.3.14)
Correctly install door seal.
(Refer service section 6.3.14)
POWER SWITCH DOES NOT
SWITCH UNIT OFF
Power switch faulty.
(Refer fault diagnosis 6.1.15)
Broil relay faulty (E25B only).
(Refer fault diagnosis 6.1.15)
Heating relay faulty (E25B
only).
(Refer fault diagnosis 6.1.15)
Replace.
(Refer service section 6.3.4)
Replace.
(Refer service section 6.3.8)
Replace.
(Refer service section 6.3.8)
