Moffat turbofan E25 - Fan; Motor; Outer Glass

Revision 6/F3501
© Moffat Ltd, August 2006 E25 Convection Oven
-25-
Three Screws
Centre Nut
6.3.12 OUTER GLASS ( E25 / E25B)
6.3.11 MOTOR
6.3.10 FAN
1) Remove fan (refer 6.3.10), remove service
panel (refer 6.2.2) and then remove the
wires that go to the motor.
2) Undo the four screws holding the motor
bracket in place (from the outside) and
remove motor assembly.
3) Remove three screws holding motor to
bracket and remove motor. (fig 6.3.12)
4) Replace and re-assemble in reverse
order.
5) Ensure wire connections are correct
(fig 6.3.13 and 6.3.14)
1) Open the oven door.
2) Lock hinges into position by rotating the
hinge locking clip over the hinge locking
notch.
2) Replace and re-assemble in reverse
order.
NOTE:
Reassemble with spacer behind fan.
or
Reassemble with one washer behind
fan, and one washer in front.
3) Lift door away from the oven and place on
a flat surface.
4) Undo two screws and remove the trim
from the bottom of the door. Carefully
withdraw the glass.
Figure 6.3.11
Figure 6.3.13
Screws (4)
Figure 6.3.12
Phase
Terminal
Earth /
Ground
Neutral
Hinge Locking Clip
Hinge Locking
Notch
Figure 6.3.15
1) With baffle removed (refer 6.2.3) undo the
centre nut.
NOTE
: LH thread - Turn clockwise to loosen.
From S/N 251948 Take care with
spacer.
Up to S/N 251947 Take care not to
lose the two washers.
Screws (4)
60 Hz
Terminal
50 Hz
Terminal
Earth /
Ground
Neutral
Figure 6.3.14
220 - 240V Motors (from S/N 251948)
220 - 240V Motors (up to S/N 251947)
110V Motors (all)
