© Moffat Ltd, August 2006 E25 Convection Oven
-39-
Pos Part No. Description
1 012809 OVEN RACK
2 011402 PIVOT TOP COVER - E25 / E25B
005040 PIVOT TOP COVER - E25MS / E25BMS
3 023074 LINTEL SUPPORT
4 023087 WRAPPER
5 022042 FAN
6 003016 MOTOR PLATE
7 013431K MOTOR - 240V (From S/N 251948)
023215 MOTOR – 240V (Up to S/N 251947)
7 025387 MOTOR – 110V
8 004857 OVEN
9 017770 PHIAL GUARD
10 023093 MICROSWITCH MOUNTING BRACKET
11 012520 OVEN LIGHT ASSEMBLY – 240V
11 023216 OVEN LIGHT ASSEMBLY – 110V
12 013977 MICROSWITCH INSULATION
13 003004 MICROSWITCH
14 023067 SIDE RACK RH
15 023073 COVER PANEL
16 002138 CABLE CLAMP
17 002441 INSULATOR
18 013586 TERMINAL BLOCK
19 018251 CABLE ENTRY
20 023089 INSULATION PANEL
21 023088 BODY
22 013908 FOOT
23 ---------- CONTROL PANEL
(Refer to section 11.3 / 11.4)
24 023071 FAN ELEMENT – 240V
24 023069 FAN ELEMENT – 110V
25 023382 BAFFLE RA
26 023217 DOOR HINGE
27 023282 BOTTOM TRIM
28 023091 GLASS CLAMP ANGLE
(Refer to section 11.5 for E25MS door)
29 023063 INNER GLASS (Refer to section 11.5 for E25MS door)
30 023062 OUTER GLASS
(Refer to section 11.5 for E25MS door)
31 023228 INNER GLASS SEAL
(Refer to section 11.5 for E25MS door)
32 023230 OUTER GLASS SEAL
(Refer to section 11.5 for E25MS door)
33 004854 DOOR INNER PANEL
(Refer to section 11.5 for E25MS door)
34 021468 DOOR HANDLE
(Refer to section 11.5 for E25MS door)
35 023281 TOP TRIM
(Refer to section 11.5 for E25MS door)
36 023090 HANDLE STIFFENER
(Refer to section 11.5 for E25MS door)
37 041410 M8 X 20
38 004868 BOTTOM BAFFLE
39 023066 SIDE RACK LH
40 023095 VENT TUBE
41 044215 CAGE NUT
42 023068 SIDE RACK SCREW
43 023384 BAFFLE PIVOT WA
44 023387 BAFFLE SUPPORT
45 013610 DOOR BUSH
46 044210 SPIRE CLIP
47 021637 MICROSWITCH BUTTON
48 014226 TOP SEAL
49 023219 HINGE COUNTER BRACKET
50 023099 SIDE SEAL
