© Moffat Ltd, August 2006 E25 Convection Oven
-41-
Pos Part No. Description
1 012809 OVEN RACK
2 011402 PIVOT TOP COVER - E25 / E25B
005040 PIVOT TOP COVER - E25MS / E25BMS
3 023074 LINTEL SUPPORT
4 023087 WRAPPER
5 022042 FAN
6 003016 MOTOR PLATE
7 025387 MOTOR (110V)
8 023075 OVEN
9 017770 PHIAL GUARD
10 023093 MICROSWITCH MOUNTING BRACKET
11 023216 OVEN LIGHT ASSEMBLY (110V)
12 013977 MICROSWITCH INSULATION
13 003004 MICROSWITCH
14 023067 SIDE RACK RH
15 023073 COVER PANEL
16 002138 CABLE CLAMP
17 002441 INSULATOR
18 013586 TERMINAL BLOCK
19 023213 RELAY (110V)
20 018251 CABLE ENTRY
21 023089 INSULATION PANEL
22 023088 BODY
23 013908 FOOT
24 --------- CONTROL PANEL
(refer to section 11.3 / 11.4)
25 023070 FAN ELEMENT (110V)
26 023382 BAFFLE RA
27 023389 BOTTOM BAFFLE
28 023217 DOOR HINGE
29 023282 BOTTOM TRIM
30 023091 GLASS CLAMP ANGLE
(Refer to section 11.5 for E25MS door)
31 023063 INNER GLASS (Refer to section 11.5 for E25MS door)
32 023062 OUTER GLASS
(Refer to section 11.5 for E25MS door)
33 023228 INNER GLASS SEAL (Refer to section 11.5 for E25MS door)
34 023230 OUTER GLASS SEAL (
Refer to section 11.5 for E25MS door)
35 004854 DOOR INNER PANEL (
Refer to section 11.5 for E25MS door)
36 023384 BAFFLE PIVOT WA (
Refer to section 11.5 for E25MS door)
37 021468 DOOR HANDLE (
Refer to section 11.5 for E25MS door)
38 023281 TOP TRIM (
Refer to section 11.5 for E25MS door)
39 023090 HANDLE STIFFENER (
Refer to section 11.5 for E25MS door)
40 041410 M8 X 20
41 023072 GRILL ELEMENT (110V)
42 003219 ELEMENT SUPPORT
43 023068 SIDE RACK SCREW
44 044215 CAGE NUT
45 023066 SIDE RACK LH
46 023095 VENT TUBE
47 023387 BAFFLE SUPPORT
48 013610 DOOR BUSH
49 044210 SPIRE CLIP
50 021637 MICROSWITCH BUTTON
51 014226 TOP SEAL
52 023219 HINGE COUNTER BRACKET
53 023099 SIDE SEAL
