Moffat turbofan E25 - Page 6

Revision 6/F3501
© Moffat Ltd, August 2006 E25 Convection Oven
-6-
LOCATION
To ensure correct ventilation for the motor and
controls the following minimum installation
clearances are to be adhered to:
Top 200mm / 8”
Rear 25mm / 1”
Left-hand side 25mm / 1”
Right-hand side 25mm / 1”
OVEN INTERNAL DIMENSIONS
Width 470 mm / 18.5”
Height 254 mm / 10.0”
Depth 420 mm / 16.5”
Oven Volume 0.05 m³ / 1.75 ft³
OVEN RACK SIZE
Width 460 mm / 18”
Depth: 370 mm / 14.5”
ELECTRICAL SUPPLY SPECIFICATION
OPTIONS
E25
100-120V ac, 60Hz, 13.3A, 1.6kW @ 120V
220-240V ac, 50/60Hz, 8.5A, 2.05kW @ 240V
E25B
100-120V ac, 60Hz, 17.1A, 2.05kW @120V
ELECTRICAL PLUG SPECIFICATION
REQUIREMENTS
E25
Australia 3-pin 250V 10A, AS/NZ 3112
Canada 3-pin 120V 15A, NEMA 6-15
New Zealand 3-pin 250V 10A, AS/NZ 3112
United Kingdom 3-pin 250V 13A fused, BS
1363A
United States 3-pin 120V 15A, NEMA 6-15
Other Countries 3-pin 250V 10A minimum,
type to meet country
standards
E25B
Canada 3-pin 120V 20A, NEMA 6-20
United States 3-pin 120V 20A, NEMA 6-20
