SpectraMax ABS and SpectraMax ABS Plus Microplate Spectrophotometers User Guide
14 5065390 C
Connecting Instrument Cables
The power cord and USB cable connect to the ports on the rear of the instrument.
Illustration Part Number Description
5064799 USB computer connection cable, 3meter (9.8foot)
4400-0002 or 4400-0036 Power cord, 1meter (3.3foot)
Note: Before you connect or disconnect the power cord, make sure that the power
switch that is on the rear of the instrument is in the Off position.
1. Make sure that the power switch that is on the rear of the instrument is in the Offposition.
2. To use a computer to operate the instrument, connect the appropriate end of the supplied
USB cable to the USB port that is on the rear of the instrument, and then connect the other
end to a USB port on the computer.
3. Connect the supplied power adapter to the power port that is on the rear of the instrument,
and then connect the other end to a grounded electrical wall outlet.
4. Turn the instrument around so that the front of the instrument now faces you.
Note: Ensure no cables run beneath the instrument.
5. Remove the tape from the cuvette door on the SpectraMax ABSPlus.
6. Power on the instrument and wait for the plate drawer to open.
