SpectraMax iD3 Multi-Mode Microplate Reader Installation Guide
11 5054744 C
Item Description
1 Screw #1 fastens the lock to the internal frame of the instrument
2 Screw #2 fastens the lock to the plate drawer
3 Screw #3 fastens the lock to the plate drawer
4 Plate drawer
5 Plate door in open position
6 Plate drawer transport lock
Plate Drawer Transport Lock
6. Loosen screws #2 and #3 until the lock comes free of the plate drawer and you can
remove the lock from the instrument. The screws have retaining washers that prevent
them from being removed from the lock. Store the transport lock in the accessories tool
box included with the microplate reader.
7. Push the plate drawer back inside the instrument and close the chamber door.
8. Save the original carton, foam inserts, accessories tool box, and transport locks for
future shipments.
