molex MX150 - Table of Contents

APPLICATION SPECIFICATION
REVISION: ECR/ECN INFORMATION: SHEET No.
EC No:
ABC2001-9999
1
DATE:
2008/16/03
TITLE:
MX150 Application Guide
2 of 62
DOCUMENT NUMBER: CREATED / REVISED BY: CHECKED BY: APPROVED BY:
AS
-
33472
-
100
Brian Zelinski Steve Verzyl Scott Marceau
TEMPLATE FILENAME: APPLICATION_SPEC[SIZE_A](V.1).DOC
Table of Contents
• Section 1: Product Introduction
• Section 2: Product Summary
• Section 3: Connector Assembly
• Section 4: Connector Mating
• Section 5: Service Instructions
• Section 6: Electrical Continuity Checking
• Section 7: Crimping
• Section 8: Hybrid Connector
• Section 9: Troubleshooting Guide
• Section 10: Packaging
