APPLICATION SPECIFICATION
REVISION: ECR/ECN INFORMATION: SHEET No.
EC No:
ABC2001-9999
1
DATE:
2008/16/03
TITLE:
MX150 Application Guide
11 of 62
DOCUMENT NUMBER: CREATED / REVISED BY: CHECKED BY: APPROVED BY:
Brian Zelinski Steve Verzyl Scott Marceau
TEMPLATE FILENAME: APPLICATION_SPEC[SIZE_A](V.1).DOC
TPA’s shown in pre-lock
TPA’s shown in “As Shipped” condition.
The TPA should remain in the pre-lock position until all circuits are
loaded. TPA movement distance from pre-lock to final lock = 5.0 mm
in both Blade and Receptacle connectors.
The TPA should never be removed from the connector!
Section 3: Connector Assembly
A. “As Shipped” connector positions
