TPA shown in “Pre
-
lock” position.(Fig.10
-
a)
TPA shown in “lock” position. (Fig 10-b)
The TPA should never be removed from the connector!
Cross section of TPA in pre/ lock
Pre-lock
Lock
Section 3: Connector
Assembly
B. TPA in Pre-lock and Lock
5.0 mm
Fig. 10
-
a
Fig. 10
-
b
