Section 7: Crimping
This MX150 crimping information can be found
at:
www.molex.com/ind/mx150.html
MX150 Terminal Sales drawing
MX150 Female Terminal Sales Drawing: SD-33012-002
MX150 Female Terminal Crimping Specification: CS-33012-002
MX150 Male Blade Terminal Sales Drawing: SD-33000-001
MX150 Male Blade Terminal Crimping Specification: CS-33000-001
